Webb Follows Neon Signs Toward New Thinking on Planet Formation

Scientists are following neon signs in a search for clues to one planetary system’s future and the past of another – our own solar system. Following up on a peculiar reading by NASA’s previous infrared flagship observatory, the now-retired Spitzer Space Telescope, the agency’s James Webb Space Telescope detected distinct traces of the element neon in the dusty disk surrounding the young Sun-like star SZ Chamaelontis (SZ Cha).

Image: SZ Chamaeleontis Protoplanetary Disk (Artist Concept )

Looking in from the outer edge of a dusty, spinning disk surrounding a bright central star, which is illustrated as an indistinct bright region in the center of the disk. Rays of light emanate from the central area. A dark gap in the disk appears between the bright core and the dusty, hazy outer regions, which build up slightly as you move outward, so that the core appears sunken. The outer disk has some bands of varying thickness, in varying shades of orange.

In this artist concept, the young star SZ Chamaeleontis (SZ Cha) is surrounded by a disk of dust and gas with the potential to form a planetary system. Once our solar system looked something like this, before planets, moons, and asteroids formed. The raw ingredients, including those for life on Earth, were present in the Sun’s protoplanetary disk. SZ Cha emits radiation in multiple wavelengths which are evaporating the disk. Planets are in a race against time to form before the disk of material is evaporated completely. NASA’s James Webb Space Telescope observed typical conditions in the disk – it was being bombarded primarily by X-rays. However, when NASA’s Spitzer Space Telescope observed the disk in 2008, it saw a different scene, dominated by extreme ultraviolet (EUV) light, indicated by the presence of a specific type of neon in the disk. These differences are significant because planets would have more time to form from a disk dominated by EUV. Astronomers are investigating the cause of the difference between Webb and Spitzer’s readings, and think it may be due to the presence (or not) of a strong wind that, when active, absorbs EUV, leaving X-rays to hit the disk.

NASA, ESA, CSA, Ralf Crawford (STScI)

Differences in the neon readings between Spitzer and Webb point to a never-before-observed change in high-energy radiation that reaches the disk, which eventually causes it to evaporate, limiting the time planets have to form.

“How did we get here? It really goes back to that big question, and SZ Cha is the same type of young star, a T-Tauri star, as our Sun was 4.5 billion years ago at the dawn of the solar system,” said astronomer Catherine Espaillat of Boston University, in Massachusetts, who led both the 2008 Spitzer observations and the newly published Webb results. “The raw materials for Earth, and eventually life, were present in the disk of material that surrounded the Sun after it formed, and so studying these other young systems is as close as we can get to going back in time to see how our own story began.”

Scientists use neon as an indicator of how much, and what type, of radiation is hitting and eroding the disk around a star. When Spitzer observed SZ Cha in 2008, it saw an outlier, with neon readings unlike any other young T-Tauri disk. The difference was the detection of neon III, which is typically scarce in protoplanetary disks that are being pummeled by high-energy X-rays. This meant that the high-energy radiation in the SZ Cha disk was coming from ultraviolet (UV) light instead of X-rays. Besides being the lone oddball result in a sample of 50-60 young stellar disks, the UV vs. X-ray difference is significant for the lifetime of the disk and its potential planets.

Image: Neon Gas In Protoplanetary Disk

Infographic titled SZ Chamaeleontis, Neon Gas in Protoplanetary Disk. Text at top right reads MIRI, Medium Resolution Spectroscopy. Two spectra lines are compared, labeled in a key as yellow being Webb 2023, and white being Spitzer 2008. Behind the spectra an illustration of a protoplanetary disk shows through, with a very bright center. Two squiggly lines are compared, with yellow, the Webb data, shown on top of the Spitzer data. Just before 13 microns on the X axis, a green column highlights a tall vertical spike in both spectra. They are labeled Neon, N E Roman numeral two. Between 15 and 16 microns, a purple column highlights a shorter vertical spike in the Spitzer spectrum, which is contrasted with a very small peak in the Webb spectrum. This purple column, and the peaks it highlights, are labeled Neon, N E Roman numeral three. See extended description for more.

Contrasting data from NASA’s James Webb and Spitzer space telescopes show change in the disk surrounding the star SZ Chamaeleontis (SZ Cha) in just 15 years. In 2008, Spitzer’s detection of significant neon III made SZ Cha an outlier among similar young protoplanetary disks. However, when Webb followed up on SZ Cha in 2023, the ratio of neon II to III was within typical levels. All of this is significant because protoplanetary disks are the stuff of future planetary systems – and those potential planets are in a race against time. Astronomers use neon as an indicator of the dominant radiation hitting the disk and causing it to evaporate. When extreme ultraviolet light is dominant, there is more neon III. That is the unusual circumstance that Spitzer observed in 2008. Typically, a disk is dominated by X-ray radiation, which evaporates the disk more quickly, leaving planets less time to form.
Researchers think the dramatic differences in neon detections are the result of a wind that, when present, absorbs ultraviolet light and leaves X-rays to pummel the disk. They will continue using Webb to find other examples of variability in disk conditions, working toward a better understanding of how planetary systems develop around Sun-like stars.

NASA, ESA, CSA, Ralf Crawford (STScI)

“Planets are essentially in a race against time to form up in the disk before it evaporates,” explained Thanawuth Thanathibodee of Boston University, another astronomer on the research team. “In computer models of developing systems, extreme ultraviolet radiation allows for 1 million more years of planet formation than if the evaporation is predominately caused by X-rays.”

So, SZ Cha was already quite the puzzle when Espaillat’s team returned to study it with Webb, only to find a new surprise: The unusual neon III signature had all but disappeared, indicating the typical dominance of X-ray radiation.

The research team thinks that the differences in neon signatures in the SZ Cha system are the result of a variable wind that, when present, absorbs UV light and leaves X-rays to pummel the disk. Winds are common in a system with a newly formed, energetic star, the team says, but it is possible to catch the system during a quiet, wind-free period, which is what Spitzer happened to do.

“Both the Spitzer and Webb data are excellent, so we knew this had to be something new we were observing in the SZ Cha system – a significant change in conditions in just 15 years,” added co-author Ardjan Sturm of Leiden University, Leiden, Netherlands.

Espaillat’s team is already planning more observations of SZ Cha with Webb, as well as other telescopes, to get to the bottom of its mysteries. “It will be important to study SZ Cha, and other young systems, in multiple wavelengths of light, like X-ray and visible light, to discover the true nature of this variability we’ve found,” said co-author Caeley Pittman of Boston University. “It’s possible that brief, quiet periods dominated by extreme UV radiation are common in many young planetary systems, but we just have not been able to catch them.”

“Once again, the universe is showing us that none of its methods are as simple as we might like to make them. We need to rethink, re-observe, and gather more information. We’ll be following the neon signs,” said Espaillat.

This research has been accepted for publication in Astrophysical Journal Letters.

The James Webb Space Telescope is the world’s premier space science observatory. Webb is solving mysteries in our solar system, looking beyond to distant worlds around other stars, and probing the mysterious structures and origins of our universe and our place in it. Webb is an international program led by NASA with its partners, ESA (European Space Agency) and the Canadian Space Agency.
